Gasonics 885-2423 Arm Control Board

Brand:Gasonics
Model: 885-2423
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Gasonics 885-2423 Arm Control Board

Product manual:

Product Name: Gasonics 885-2423 Arm Control Board
Component type: Robot Arm Controller PCB
Main function: Used to control the movement behavior of the internal transfer arm (Transfer Arm/Robot Arm) of the equipment, achieving automatic transfer of wafers between various process areas

1、 Mechanical arm drive and control
This control board serves as the core control unit, coordinating the operation of servo motors, stepper drivers, position sensors, and other components to achieve precise wafer picking, placing, and movement.

Typical control functions:

Wafer picking/placing action control

Sending commands for arm horizontal/vertical movement

Clamping device opening and closing control

Action path planning and position calibration

2、 Signal input/output interface
Establish multi-channel signal interaction between the control board, sensors, and actuators, including position feedback, action confirmation, limit protection, etc., to ensure the safety and reliability of the handling process.

Interface support:

Multi axis motor drive signal

Encoder/limit switch feedback input

Movement completion and error signal feedback

Communication interface of upper system (such as TTL, RS-232)

3、 Equipment automation system integration
The 885-2423 control board is usually integrated into Gasonics plasma equipment or other wafer processing platforms, working together with the main controller to complete material handling tasks in the process flow.

Common matching components:

Control motherboard (such as ABX-88919-41)

Stepper driver (such as RD-323M10)

Optical sensors (such as A89-004-01)
