Gasonics 943-0046-02 LCD Components

Brand:Gasonics
Model: 943-0046-02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Gasonics 943-0046-02 LCD Components

Product manual:

product name
Gasonics 943-0046-02 LCD Display Component
(English: LCD Display Assembly)

1、 Product Overview
Gasonics 943-0046-02 is a liquid crystal display component applied to Gasonics series plasma equipment, usually installed as part of the human-machine interface (HMI) on the front panel or console of the equipment, used to display key content such as process parameters, alarm information, menu operation interface, etc. This module receives data through the system control board and displays it in real-time, providing operators with intuitive feedback on equipment status.

2、 Technical parameters
Display type: Liquid Crystal Display (LCD)

Screen specifications:

Usually monochrome or grayscale character LCD (specific models may be graphic dot matrix or character type)

Typical character row and column configurations such as 4x20 or 2x40 (depending on version)

Interface method:

Connect the flat cable to the main control board or display control card

The communication method may be parallel port or serial port (such as RS232, SPI)

Supply voltage:+5V DC or+12V DC (depending on backlight and control circuit)

Control circuit: may integrate display driver chips (such as HD44780 or compatible devices)

Panel installation:

With fixed screw holes, it can be installed on the front panel of the chassis

The panel may be equipped with a transparent protective window
