Gasonics 95-0289 Circuit Board

Brand:Gasonics
Model: 95-0289
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Gasonics 95-0289 Circuit Board

Product manual:

Product Name: Gasonics 95-0289 Circuit Board
Component type: Signal Control/Processing Circuit Board (Control or Interface PCB)
Main function: Perform core functions such as logic control, signal processing, or system communication in Gasonics plasma cleaning equipment

1、 Core of internal control logic of equipment
The Gasonics 95-0289 circuit board is typically used as a functional sub board in system control architecture,

Used to perform critical tasks in equipment automation processes.

Possible uses:

Managing the timing logic of plasma processing

Control gas on/off, power module or valve

Receive and relay commands and feedback signals from HMI, PLC, and I/O modules

2、 Used in conjunction with the main control or interface panel
This circuit board may serve as a matching controller for interface boards (such as A95-108-02 panel),
Responsible for processing user input signals and converting them into control instructions, or executing action control from the main control system.

Typical connection module:

Operation panel buttons/LED indicator lights

Stepper motor drive control cable

Sensor feedback input channels (such as door position, chamber pressure, temperature)

3、 Signal isolation and protection function
To protect the signal security between the main control system and high-power loads,
The 95-0289 circuit board may include functional modules such as optocoupler isolation, filtering, and surge suppression.

Common protective applications:

Control relay on/off

Filter electromagnetic interference (EMI) signals

Avoid high-frequency interference affecting logical judgment
