Gasonics A60-002-03 Transformer

Product manual:

product name
Gasonics A60-002-03 Transformer
(English: Transformer Module)

1、 Product Overview
Gasonics A60-002-03 is a process power transformer used in Gasonics series plasma cleaning/ashing equipment, mainly used to convert mains or system power into stable AC or DC voltage required by the internal electronic modules of the equipment. This transformer is generally located in the power supply subsystem and serves as a key power supply foundation for components such as current drive, control module, valve control card, and power filtering device.

2、 Technical parameters
Type: Power Isolation Transformer/Process Control Power Transformer

Input voltage:

Usually 208VAC, 220VAC, or 240VAC (three-phase or single-phase, depending on region/configuration)

Output voltage:

Multiple outputs, such as 24VAC, 12VAC, ± 15VAC, or 5VDC (the secondary side can be used by multiple modules)

Power level:

Typically ranging from tens to hundreds of VA (depending on model and usage)

Insulation level:

Industrial grade insulation treatment with overload and over temperature protection functions

Cooling method:

Natural air cooling or forced air cooling (depending on the installation environment)

Encapsulation structure:

Iron core encapsulation/iron shell shielding structure, suitable for high EMI environments

Installation method:

Panel or base plate bolt installation, equipped with standard terminals or lead connectors

Certification and Standards:

Meets industrial equipment electrical safety standards and may have UL or CE markings (depending on version)

Product details picture:

A60-002-03
