Gasonics A90-003-01 A89-003-01 Control Module

Brand:Gasonics
Model:A90-003-01 A89-003-01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Gasonics A90-003-01 A89-003-01 Control Module

Product manual:

1、 Product Overview
Gasonics A90-003-01 and A89-003-01 are control modules in Gasonics plasma processing equipment,
Mainly used as a system control board or interface board to coordinate the operation of various subsystems in the equipment,
Modules such as plasma source control, chamber vacuum system, lifting platform, gas flow rate, load lock handling, etc.
This module is usually installed inside the main control chassis of the device, and completes the control logic of the whole machine by connecting the main CPU board with components such as actuators and sensors.

2、 Application Fields
1. Plasma Asher equipment
Control the RF power output, gas channel, solenoid valve, and vacuum pump operation status;

Integrate with HMI touch screen/control panel to execute user commands.

2. Load lock system and automatic handling unit
Control the upper and lower arm, load lock chamber vacuum switching, and lifting mechanism actions;

Linkage with robot arms and chamber doors to achieve precise handling processes.

3. System bus and sensor interface control
Receive sensor signals such as temperature, pressure, and flow rate;

Send a switch to the execution unit PWM、 Simulate voltage/current control signals.

4. Equipment safety and interlocking system
Implement hardware security mechanisms such as system level alarm response, emergency stop control, and door lock linkage;

Support self check, self recovery, and anomaly diagnosis.
