Gasonics A90-039-01 Current Sensor

Product manual:

product name
Gasonics A90-039-01 Current Sensor
(English: Current Sensor Module)

1、 Product Overview
Gasonics A90-039-01 is a current detection module designed specifically for Gasonics series plasma equipment, mainly used to monitor the current status of key components such as heaters, RF power supplies, solenoid valves, etc. This module converts real-time current signals into analog signals and transmits them to the main control system, achieving closed-loop control, status monitoring, and fault protection.

2、 Technical parameters
Module Type: Current Sensor/Current Monitoring Module

Typical application current range: 0-20 A (specific range depends on the application load)

Output signal:

Analog output (such as 0-5V or 0-10V)

Or current output (such as 4-20 mA)

Detection principle: Based on Hall effect or transformer current mutual inductance principle (depending on the specific version)

Insulation characteristics: Electrical isolation between input and output

Supply voltage:+15V DC/+24V DC (depending on specific module specifications)

Response time: Fast response, suitable for monitoring dynamic process currents

Interface type: Multi pin terminal or ribbon cable interface, connected to the main control board or acquisition system

Installation method: Modular plug-in board or fixed installation in the internal power area of the device

Product details picture:

A90-039-01
