GDC801A 3BHE0247R0101 Control Board

Brand:ABB
Model:GDC801A 3BHE024747R0101
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

GDC801A 3BHE0247R0101 Control Board

Product manual:

ABB GDC801A (order number 3BHE024747R0101) is a control board used in medium voltage frequency converter systems, commonly found in ABB's ACS2000, ACS5000 and other medium voltage drive systems. It mainly plays a role in control, communication, and monitoring signal processing.

1、 Basic information:
Product Model: GDC801A

Order number: 3BHE024747R0101

Manufacturer: ABB

Product Type: Control Board/Control Logic Module

Typical application equipment: ACS2000, ACS5000 medium voltage frequency converter system

2、 Functional features:
As the core control board of the system, it is used to coordinate the operation of various modules inside the frequency converter

Realize the processing and transmission of control signals and status information

The communication interface supports data exchange with the upper computer and other control modules

The board contains a processor, storage chip, communication interface, and protection circuit

Support long-term stable operation in industrial environments

3、 Technical parameters (conventional):
Working voltage: 24V DC

Working temperature range: -20 ° C to+60 ° C

Storage temperature range: -40 ° C to+85 ° C

Protection level: Coating protection, suitable for industrial sites

Size: Approximately 376mm x 140mm x 75mm

Weight: Approximately 0.72 kg

4、 Applicable fields:
Medium voltage motor drive system in the power industry

Heavy duty working conditions such as petrochemicals, metallurgy, and mining
