GE DS3800HMPK1K1K Controller Module

Product manual:

1、 Product Overview
DS3800HMPK1K1K is a controller module in the Mark IV series control system of General Electric (GE).
This module is widely used in GE's turbine control systems, such as gas turbine or steam turbine control,
Used to achieve precise monitoring, control, and data processing functions. This model is mainly used as one of the main processing modules,
Integrated with microprocessor, memory, and data communication functions, used to perform critical control tasks in the control system.

2、 Technical parameters
Product Series: GE Speedtronic Mark IV

Module Number: DS3800HMPK1K1K

Function type: Main control processor module (Microprocessor Board)

Interface features:

Multiple pin banks

Match GE Backplane bus connection

Support on-site data collection and execution of logical instructions

Chip configuration: Integrated high-performance microprocessor (Motorola or Intel series)

Memory support: onboard static RAM and EPROM chips for firmware loading and data caching

Diagnostic function: with fault self check (LED status indication)

Size specification: Standard 6U plug-in board size, suitable for GE control system rack

3、 Application scenarios
Gas Turbine Control System
In the GE Mark IV control architecture, DS3800HMPK1K1K is one of the core processing modules,
Control key parameters such as combustion, ignition, speed, pressure, etc.

Steam Turbine Control System
Used to control steam flow, valve position, and unit start stop logic, achieving automated regulation and protection of the system.

Process control of power plants
Applied in the distributed control system of power plants, it achieves coordinated control of subsystems such as boilers, turbines, and electrical protection.

industrial process control system
It can be used for real-time data acquisition and logical control of key processes in large-scale continuous production systems such as metallurgy and petrochemicals.
