GE IS230PCAAH1A Analysis of I/O Components

Brand:GE
Model: IS230PCAAH1A
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

GE IS230PCAAH1A Analysis of I/O Components

Product manual:

product name
GE analyzes I/O components for 230pcah1a
(English description: GE Mark VIe input/output package - IS230PCAAH1A analog input module)

1、 Product Overview
230pcaah1a is an analog input I/O module (I/O pack) used in the General Electric Mark VIe control system
Used to collect simulated signals on site and transmit them to controllers (such as Mark VIe or Mark VIeS systems).
This module has high precision, industrial grade anti-interference capability, and system redundancy support,
Widely deployed in GE's gas turbines, steam turbines, compressors, and power plant automation systems.

2、 Technical parameters
Module Type: Analog Input Module (Analog Input/Output Package)

Product Series: GE Mark VIe/VIeS Control System

Model code: 230pcaah1a

Input signal type:

Current input (4-20mA, 0-20mA)

Voltage input (± 5V, ± 10V) - depends on the configuration of the I/O terminal board

Number of channels: Typically 10-20 analog input channels (depending on the type of terminal board connected)

Communication interface:

Communicate with the controller through IONet network (redundant Ethernet)

The I/O package is installed on the terminal board and connected to the signal and power through the backplane

Power requirements:

Backup power supply from I/O terminal board (usually 28 VDC)
