GIDINGS&LEWIS501-04052-00memory circuit board

Product manual:

GIDINGS&LEWIS 501-04052-00 memory circuit board
Product Overview

GIDINGS&LEWIS 501-04052-00 memory circuit board is a core module used in industrial automation control systems, mainly for storing programs, process parameters, control data, and historical operating information.
This module can ensure that the control system saves critical data in the event of power failure or malfunction, achieving rapid recovery and stable operation.
Memory circuit board is an indispensable storage unit in CNC machine tools, automated production lines, and servo systems.

Technical parameters (typical characteristics, actual values need to refer to official materials)

Storage type: Industrial grade SRAM/EEPROM

Capacity: Supports storage of system programs, parameters, and operational data

Data retention: equipped with power-off retention function to prevent data loss

Interface mode: Compatible with controllers and bus modules, supporting high-speed data access

Installation form: Modular circuit board, slot installation

Environmental adaptability: Industrial grade design, resistant to high temperature, vibration, and electromagnetic interference

Application scenarios

Numerical Control Machine Tool (CNC)

Store machining programs, tool compensation data, and workpiece parameters to ensure machining accuracy and repeatability.

Automatic production line

Save the process sequence, workstation configuration, and testing data to achieve production flexibility and quick switching.

Servo and motion control system

Store motor debugging parameters, motion trajectory data, and operation logs to ensure rapid system recovery after power failure.

Store key control parameters and protection logic to improve the reliability and safety of equipment such as generator sets and substations.

Product advantages

Data security and reliability: Designed to withstand power outages and prevent the loss of important data.

Industrial grade stability: adaptable to harsh environments, strong resistance to vibration and electromagnetic interference.

High speed access: supports fast read and write, improving the response speed of the control system.

Product details picture:

501-04052-00
