GIDINGS&LEWIS 501-04301-02 AC Output Module
Brand:GIDDINGS & LEWIS
Model:501-04301-02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
GIDINGS&LEWIS 501-04301-02 AC Output Module
Product manual:
Product Overview
GIDINGS&LEWIS 501-04301-02 AC output module is a core execution module used in industrial automation and numerical control systems. It is mainly responsible for converting the instructions issued by the controller into AC signals, driving servo motors, AC relays, contactors or other AC actuators, thereby achieving precise action control. This module is usually used as a key interface component for CNC machine tools and automated production lines, ensuring the accuracy and reliability of executing actions.
Technical parameters (typical)
Output type: AC voltage/current output
Output channel: Multi channel design, capable of driving multiple execution devices
Voltage level: commonly used industrial AC voltage (such as 120V/230V/380V AC)
Control mode: switch control, pulse control, or adjustable amplitude output
Interface compatibility: Can be used in conjunction with G&L controllers and other standard industrial controllers
Response speed: High responsiveness, meeting the requirements of fast action control
Protection function: Short circuit, overload, overvoltage protection, ensuring the safety of modules and equipment
Installation method: Modular plug-in board design, easy to expand and replace
Status indication: LED displays output status and fault diagnosis information
Application scenarios
CNC machine tool
Drive the spindle, feed shaft, or other AC loads to achieve high-speed cutting and precise positioning.
Automatic production line
Control communication motors, pumps, fans, and other equipment to achieve action synchronization and process control.
industrial robot
Provide AC power to joints or end effectors to achieve precise motion execution.
Packaging and Printing Machinery
Control the AC drive of cutting, feeding, and packaging equipment to ensure high cycle time and stability.
textile machinery
Drive the winding machine, tension control device, and feeding system to improve process stability.
Experimental and testing platform
Used for action control and dynamic testing of communication loads, achieving multi-channel precise execution.
Product details picture:
501-04301-02
