GIDINGS&LEWIS 501-92501-00 linear inch ruler

Brand:GIDDINGS & LEWIS
Model:501-92501-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

GIDINGS&LEWIS 501-92501-00 linear inch ruler

Product manual:

GIDINGS&LEWIS 501-92501-00 linear inch ruler
Product Overview

The Giddings&Lewis 501-92501-00 linear inch ruler is a precision position measurement component,
Usually used for linear axis positioning and feedback in large CNC machine tools, boring machines, or milling machines.
This ruler is measured in inches and mainly provides high-precision linear displacement detection signals for machine tools,
It is an important component for CNC systems to achieve precision machining control.

Technical Features

High precision: Measuring in inches to ensure positioning accuracy during large stroke machining.

Reliable and durable: suitable for heavy-duty machine tool environments, able to resist vibration, dust, and cutting fluid effects.

Feedback signal: Provide real-time displacement and position feedback for the CNC system of the machine tool.

Strong compatibility: Suitable for various CNC machine control systems of G&L.

Application field

Large boring and milling machines
Used for linear position detection of spindle or worktable, ensuring precise positioning under large stroke.

Vertical turning center and turning milling composite machine tool
Provide precise position feedback for tool holders or workbenches to improve the precision of complex surface machining.

CNC machining center
Real time monitoring and adjustment of axis motion during automated machining processes to ensure machining quality.

Machine tool transformation and upgrading
Can be used for CNC transformation of old equipment to improve positioning and measurement accuracy.

Testing and Calibration Applications
In equipment maintenance or workpiece inspection, use a reference benchmark ruler to improve process consistency.

Product advantages

Accuracy guarantee: Ensure the machining accuracy and repeatability of large workpieces.

Improve efficiency: Reduce rework caused by positional errors.

Stable and reliable: Suitable for complex working conditions in industrial sites.

Long life design: wear-resistant, resistant to environmental influences, and extends the service life.
