GIDINGS&LEWIS 502-02192-00 Control Board

Brand:GIDDINGS & LEWIS
Model:502-02192-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

GIDINGS&LEWIS 502-02192-00 Control Board

Product manual:

GIDINGS&LEWIS 502-02192-00 Control Board
Product Overview

The Giddings&Lewis 502-02192-00 control board is a core control module used for CNC machine tools and automation systems,
The main function is to receive instructions from the upper control unit (such as CPU board or servo control board),
And convert it into control signals for actuators, servo drives, or peripheral devices.
It is an important module for achieving precise motion control and multi axis linkage of machine tools.

Technical Features

Multi axis coordinated control: supports synchronous control of multi axis servo or stepper motors to achieve complex machining actions.

Real time response: High speed processing of control signals to ensure precise and timely machine tool actions.

Modular design: can be directly installed in the rack or control cabinet for easy maintenance and replacement.

Closed loop compatibility: It can cooperate with feedback devices such as encoders and rotary transformers to achieve high-precision closed-loop control.

Strong industrial adaptability: anti-interference, vibration resistant, suitable for CNC machine tools and industrial automation environments.

Application field

CNC boring and milling machines
Control the movement of the worktable, tool holder, and spindle to achieve high-precision machining.

Vertical lathe and composite machining center
Coordinate multi axis actions to achieve composite machining processes such as turning, milling, and drilling.

Automatic production line
Control the robotic arm or execution unit to achieve synchronous and precise control of production line equipment movements.

Machine tool upgrade and renovation
In the numerical control transformation of old equipment, as the core control module, it improves system accuracy and reliability.

Robots and precision mechanical equipment
Provide precise control signals and support high-speed and high-precision mechanical actions.
