GIDINGS&LEWIS 502-02307-00 Rotary Transformer Module

Brand:GIDDINGS & LEWIS
Model:502-02307-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

GIDINGS&LEWIS 502-02307-00 Rotary Transformer Module

Product manual:

GIDINGS&LEWIS 502-02307-00 Rotary Transformer Module
Product Overview

Giddings&Lewis 502-02307-00 Rotary Transformer Module
It is an interface module for position/velocity detection and feedback, mainly used in conjunction with a rotary transformer (Resolver) sensor.
Rotary transformer is a highly reliable rotating position detection device commonly used in CNC machine tools and servo drive systems.

Technical Features

Signal conversion: Convert the sine/cosine analog signal of the rotary transformer into a digital position signal.

High precision feedback: achieve real-time and high-precision detection of motor angle and speed.

Stable and reliable: adaptable to strong interference environments in industrial sites, with strong anti vibration capabilities.

Modular design: Installed in the G&L control system rack for easy maintenance and replacement.

Strong compatibility: compatible with various servo motors, spindle motors, and CNC systems.

Application field

CNC machine tool spindle control
Used for spindle angle and speed detection of large boring machines, milling machines, turning centers and other equipment to ensure machining accuracy.

Servo drive system
Provide high-precision position feedback in the feed servo motor system to achieve closed-loop control.

Machine tool positioning system
As a key feedback link, ensure the precise positioning of components such as workbenches and tool holders.

Machine tool transformation and upgrading
In the numerical control transformation of old equipment, it is used to add position detection and feedback functions.

Testing and Diagnosis
During the maintenance process of the machine tool, the rotary transformer module can be used for monitoring the feedback signals of the motor and control system.

Product advantages

High precision: Based on feedback from rotary transformers, suitable for high-precision CNC machining.

Strong reliability: More durable than grating sensors, especially suitable for heavy-duty machine tools and harsh environments.

Good real-time performance: supports fast response and stable operation of servo systems.

Easy to maintain: modular design for easy replacement and expansion.
