GIDINGS&LEWIS 502-02777-50 Digital Control Board

Brand:GIDDINGS & LEWIS
Model:502-02777-50
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

GIDINGS&LEWIS 502-02777-50 Digital Control Board

Product manual:

GIDINGS&LEWIS 502-02777-50 Digital Control Board
Product Overview

Giddings&Lewis 502-02777-50 is a digital control board used for industrial automation and numerical control systems.
It mainly undertakes data processing, instruction logic operations, and digital management of peripheral interfaces, and is a core component of CNC systems, motion controllers, and complex production equipment.
This board communicates with other functional modules through a high-speed bus to achieve centralized management of servo drives, I/O modules, and actuators.

Technical Specifications

Type: Digital Control Board

Function: Responsible for logical operations, program execution, and signal scheduling

Processing capability: Supports high-speed logic control and data processing (specific clock frequency varies with system configuration)

Interface features:

Can connect I/O modules, servo drive modules, and communication interfaces

Support multi-channel data acquisition and output

Data processing: equipped with real-time task scheduling function to ensure stable control loop

Power supply requirement:+5V DC logic power supply (typical current ranges from several hundred mA according to system configuration)

Work environment:

Temperature: 0 ° C~55 ° C

Humidity: 5%~95%, no condensation

Reliability design: supports overload protection, fault detection, and self diagnosis functions

Application scenarios

CNC machine control: used for coordinate axis control, machining path management, and servo scheduling

Automated production line: Coordinate multiple subsystems to achieve synchronous control of logic and action

Motion control system: Combining servo and stepper drive to achieve high-speed and high-precision position control

Process control: responsible for data acquisition and digital logic processing in factory automation

Equipment integration: as the core control unit applied to packaging machines, robots, testing systems, etc

Product details picture:

502-02777-50
