GIDINGS&LEWIS 502-03548-00 Input Module

Product manual:

GIDINGS&LEWIS 502-03548-00 Input Module
1、 Product Overview

502-03548-00 is an industrial input module in the Giddings&Lewis series control system, used to collect digital and analog signals from field devices and transmit the data to the controller for processing. This module is a key signal acquisition unit in CNC machine tools, automated production lines, and industrial robot systems.

2、 Technical features

Multi channel input

Provide high-precision analog input, capable of collecting voltage, current, or other industrial standard signals.

High speed signal acquisition

The input channel responds quickly, ensuring real-time acquisition of both digital and analog signals.

Meet the needs of high dynamic industrial control scenarios.

Isolation and protection function

The input channel is electrically isolated from the control bus to enhance anti-interference capability.

Built in overcurrent, overvoltage, and short-circuit protection ensures the safety of modules and systems.

Status indication function

LED indicator lights display the working status of each channel, facilitating on-site debugging and troubleshooting.

Support channel abnormal alarm and quickly locate problems.

modular installation

Can be installed on G&L control racks or standard slots for easy system expansion and maintenance.

Compatible with G&L controllers and output modules, achieving seamless integration.

Industrial grade durability

The structure is sturdy, resistant to high temperatures, vibrations, and electromagnetic interference, suitable for long-term continuous operation.

Product details picture:

502-03548-00
