GIDINGS&LEWIS 502-03567-00 output circuit board module

Brand:GIDDINGS & LEWIS
Model:502-03567-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

GIDINGS&LEWIS 502-03567-00 output circuit board module

Product manual:

Product Overview

The output circuit board module of Giddings&Lewis 502-03567-00 is an important component in the PiC900 control system,
Used to convert the logic signals of the controller into electrical output signals that can drive external loads.
It is mainly used in CNC machine tools, automated production lines, and other industrial equipment to drive actuators, relays, solenoid valves, and signal devices.

Product Features

Multi-channel Design

Provide multiple independent output points to simultaneously control multiple loads.

Isolation between channels reduces the risk of interference and fault propagation.

DC output capability

Adopting standard 24V DC output, compatible with commonly used industrial control voltages.

Each channel has stable current driving capability and can directly drive small and medium power loads.

Electrical isolation and protection

Improve system security and anti-interference performance through optoelectronic isolation design.

Built in overcurrent and short-circuit protection functions to prevent damage to modules and external devices.

Status monitoring and diagnosis

Equipped with LED indicator lights, it can display the working status of each output channel in real time.

Easy on-site maintenance and troubleshooting, reducing downtime.

Modularity and compatibility

Plug in module structure, can be directly installed on the PiC900 control system rack.

Support flexible system expansion, easy to upgrade and replace.

Industrial environment adaptability

Compliant with industrial environment anti electromagnetic interference standards, high reliability.

Through anti vibration and anti impact testing, it is suitable for long-term operation in complex environments.

summary

The 502-03567-00 output circuit board module has the characteristics of multi-channel, high reliability, isolation protection, and status visualization,
Capable of meeting the output control requirements of CNC machine tools, automated production lines, and process control systems, providing stable and safe execution signals for industrial equipment.
