GIDINGS&LEWIS 502-03616-02 Machine Control Circuit Board

Product manual:

Product Overview

The Giddings&Lewis 502-03616-02 machine control circuit board is the core module in the PiC series control system, used to perform logical control and sequential action management of machine tools or automation equipment.
It can receive signals from sensors, switches, and controllers, and drive actuators to achieve precise machine operation and automated process control.

Product application areas

CNC machine tool

Control the sequence of spindle and feed axis actions to achieve the execution of machining programs.

Manage the switch operation of machine tool fixtures, hydraulic and pneumatic devices.

Automatic production line

Coordinate the sequence of actions for conveying equipment, assembly machinery, and sorting systems.

Control the linkage of multiple devices to achieve efficient automated production.

process control system

Drive industrial valves, pumps, and alarm devices to achieve automated process control.

Provide logical judgment and sequential operation functions to ensure the safe and stable operation of the system.

Industrial equipment monitoring and safety

Integrate fault detection and emergency shutdown functions to improve equipment operation safety.

Can be combined with input/output modules to achieve real-time status monitoring and alarm processing.

Experimental and testing equipment

Control the sequence of actions of precision testing equipment to achieve high repeatability and precision operations.

Support multi-channel signal input and output to meet the requirements of complex testing processes.

Product details picture:

502-03616-02
