GIDINGS&LEWIS 502-03642-00 servo controller

Product manual:

GIDINGS&LEWIS 502-03642-00 servo controller
1. Product Overview

502-03642-00 is a high-performance servo controller module from the Giddings&Lewis PiC900 series, used for precise control of servo motor motion.
It can perform closed-loop control on the motor, manage position, speed, and acceleration, and achieve coordinated control of complex movements.
This module is designed to be compact and can be integrated into industrial control systems for high-precision machining, automation equipment, and robot systems.

2. Product features

precision motion control

Support closed-loop control of position, velocity, and acceleration to ensure smooth and high-precision movements.

Dynamic optimization function

Built in motion curve optimization can reduce vibration and mechanical impact, extending equipment life.

Multi axis support

It can work in conjunction with multiple servo drives to achieve multi axis linkage and synchronous motion.

Real time instruction response

High speed processing capability, able to quickly respond to control signals from the CPU or control system.

safety protection

Built in overload, short circuit, and abnormal state protection functions ensure the safe operation of the equipment.

Industrial environment adaptability

Anti electromagnetic interference, anti vibration design, suitable for high temperature, dust, and industrial production environments.

Modularity and easy integration

Can be installed in the PiC900 system rack for easy expansion, maintenance, and system upgrades.

3. Application Fields

Precision machine tool: controls the spindle and feed axis, supports complex tool paths and high-speed machining.

Automated assembly line: drives handling, assembly, and sorting equipment to achieve coordinated and synchronized actions.

Industrial robots: manage robotic arms and multi joint equipment to achieve path planning and precise motion control.

Detection and Measurement System: Control the mobile and rotating tables to achieve high-precision positioning and measurement.

Customized automation equipment: providing high-precision servo control for packaging, printing, logistics, or specialized industrial equipment.

Product details picture:
