GIDINGS&LEWIS 502-03644-00 DC output board

Brand:GIDDINGS & LEWIS
Model:502-03644-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

GIDINGS&LEWIS 502-03644-00 DC output board

Product manual:

Product Overview

The Giddings&Lewis 502-03644-00 DC output board is a functional module in the PiC900 series control system,
Mainly used to convert the logic signal of the controller into a DC output signal to drive external loads.
This module can provide stable driving capability for solenoid valves, relays, light indicators, and other DC actuators in industrial automation equipment.

Technical Specifications

Module type: DC digital output board

Output points: Typically designed for multi-channel output (commonly 16 or 32 points)

Output current capability: Each channel has a certain load driving capability (typically around 0.5A)

Isolation protection: equipped with photoelectric isolation to enhance the safety and anti-interference between the module and external circuits

Diagnostic function: equipped with LED status indicator lights, which can display the output status of each channel for easy debugging and maintenance

Interface method: Adopting standard backplane connection and screw terminal/plug-in terminal method for convenient wiring

Application scenarios

Machine tool control
Used for driving actuators in CNC machine tools, such as controlling lubrication pumps, solenoid valves, clamping devices, etc.

Automatic production line
It can drive the DC actuator units in conveyor belts, sorting devices, and packaging systems to achieve motion control.

Signal indication and alarm system
Drive warning lights, buzzers, and other devices to achieve status display and alarm output.

Product Features

Stable and reliable: Industrial grade design ensures long-term continuous operation.

Isolation protection: Isolation between channels and control logic enhances security and anti-interference.

Strong output capability: able to directly drive small and medium power DC loads.

Easy maintenance: LED status indication and modular design, convenient for installation, replacement, and on-site debugging.

Good compatibility: It can be directly installed in the Giddings&Lewis PiC900 control system rack and supports system expansion.
