GIDINGS&LEWIS 502-03679-02 Encoder Module
Brand:GIDDINGS & LEWIS
Model:502-03679-02
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
GIDINGS&LEWIS 502-03679-02 Encoder Module
Product manual:
GIDDINGS&LEWIS 502-03679-02 Encoder Module
1、 Product Overview
The GIDDINGS&LEWIS 502-03679-02 encoder module is an input module used for motion control and position detection,
The main function is to receive pulse signals from rotary or linear encoders and convert them into digital data that can be recognized by the control system.
It is commonly used in CNC machine tools, automated production lines, and robot systems to achieve speed monitoring, position feedback, and closed-loop control.
2、 Technical parameters (typical indicators, subject to actual conditions)
Module type: Encoder input module
Signal support: Incremental encoders (A/B/Z channels), some models can support orthogonal signals
Input voltage: 5V/12V/24V TTL or differential signal
Resolution: Depending on the accuracy of the external encoder, it can support up to several thousand to millions of pulses per revolution
Number of channels: Multi channel input, supporting dual encoder signal access
Response frequency: High frequency input, typically up to 200kHz-1MHz
Isolation method: Channel and control bus are electrically isolated
Interface method: Modular slot, compatible with GIDDINGS&LEWIS system bus
Features
Position capture and counting
Speed and direction determination
Zero point reset/reference point detection
Support real-time closed-loop control
3、 Application scenarios
CNC machine tool
Provide spindle and worktable position feedback to achieve high-precision interpolation and motion control.
robot system
Used for joint position detection and velocity feedback to improve trajectory control accuracy.
Automatic production line
Used for speed synchronization and material positioning in conveyor belts and assembly machinery.
Printing and Textile Machinery
Realize tension control and alignment accuracy control.
Testing and Inspection Equipment
Provide high-precision position feedback for moving parts to ensure experimental or production process accuracy.
Product details picture:
