GIDINGS&LEWIS 502-03840-44 servo encoder

Brand:GIDDINGS & LEWIS
Model:502-03840-44
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

GIDINGS&LEWIS DSA-007-230 servo processor

Product manual:

GIDINGS&LEWIS 502-03840-44 servo encoder
1. Product Overview

502-03840-44 is a feedback component module in the Giddings&Lewis servo control system, which belongs to the encoder supporting servo motors.
The core function of this encoder is to convert the mechanical motion (speed, angle, displacement) of the servo motor into electrical signals and provide real-time feedback to the controller for closed-loop control.

2. Technical characteristics

High resolution: capable of providing accurate position and velocity signals, meeting the high-precision requirements of CNC and automation equipment.

Real time feedback: As a closed-loop detection component of the servo system, it ensures the dynamic response and stability of the motion process.

Interface compatibility: Directly compatible with G&L control systems and servo drive units, supporting standard feedback signal output.

Anti interference design: suitable for industrial site environment, able to resist electromagnetic interference and mechanical vibration.

Modular application: usually combined with servo drives and CPU control modules to form a complete motion control system.

3. Application Fields

a) CNC machine tool

Used for boring and milling machines, lathes, and machining centers to provide real-time feedback on the position of the spindle or feed servo motor, achieving high-precision cutting and positioning.

b) Automated production line

A servo drive system applied to assembly, handling, and testing equipment, providing precise position and speed feedback.

c) Robot system

Provide angle and velocity feedback for each joint in a multi joint robot to ensure trajectory control and motion synchronization.

d) Industrial Process Control

Used for conveying, winding, tension control and other occasions, ensuring smooth operation and precise speed of the equipment.

e) Logistics and Warehouse Automation

Applied to the motion control of stacker cranes and conveyor servo motors to ensure accurate positioning of goods.
