GIDINGS&LEWIS 502-03853-20 Industrial Control System

Product manual:

Product Overview

The GIDINGS&LEWIS 502-03853-20 industrial control system is a core control unit designed specifically for CNC machine tools, automated production lines, and high-precision motion control applications. This system combines high-speed computing capability, flexible I/O expansion, and reliable communication interfaces,
Capable of providing centralized and modular control and management for complex industrial equipment.
Its core design philosophy is stability, precision, and scalability to meet diverse needs in different industrial scenarios.

Technical parameters (typical features, model related)

Processing capability: Supports high-speed logical operations and multi axis motion control.

I/O interface: Supports digital input/output, analog input/output, compatible with expansion modules.

Communication capability: Equipped with serial bus, industrial Ethernet, and fieldbus interfaces, it can interconnect with PLC, drivers, and upper computer systems.

Modular structure: supports multiple module combinations, making it easy to expand system functionality.

Power adaptation: Industrial grade power input with overvoltage, overcurrent, and short-circuit protection.

Operating environment: Supports industrial environments with high temperature, strong interference, and continuous operation.

Application scenarios

Numerical Control Machine Tool Control

Used for motion control and peripheral equipment management of lathes, milling machines, and machining centers.

Ensure efficient coordination of tool switching, spindle control, and coolant management.

Automatic production line

Control the conveying system, assembly station, and inspection unit.

Realize linkage between multiple devices and improve the automation level of the production line.

robot system

Used for joint motion control, end effector drive, and multi axis synchronous operation.

Provide high dynamic response and precise motion control.

Packaging and Printing Machinery

Ensure fast start stop, synchronous positioning, and coordinated multi-stage actions.

Support high-speed production rhythm and reduce error rate.

Process Control and Energy Management

Integrated in the process industry, used for controlling pumps, valves, sensors, and actuators.

Applied to continuous production industries such as chemical, energy, metallurgy, etc.

Product details picture:

502-03853-20
