GIDINGS&LEWIS 503-19515-20 Execution Control Board
Brand:GIDDINGS & LEWIS
Model:503-19515-20
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
GIDINGS&LEWIS 503-19515-20 Execution Control Board
Product manual:
Product Overview
GIDINGS&LEWIS 503-19515-20 Execution Control Board is a core control module designed specifically for industrial automation and CNC machine tools.
This control board can ensure reliable operation in high-speed, high-precision, and complex motion sequences.
Technical parameters (typical)
Control type: pulse output, direction control, and logic execution
Input interface: receives instructions from the main controller or logic module
Output interface: Drive multiple execution devices, including servo, relay, and stepper drivers
Signal compatibility: Industrial standard level, such as 24VDC
Response speed: High speed pulse output, suitable for multi axis synchronous control
Protection mechanism: Overload, short circuit, overvoltage, and signal abnormality protection
Installation method: Modular plug-in card, easy to install in control cabinets or racks
Status indication: LED displays the working status of each channel for easy debugging and fault diagnosis
Application scenarios
CNC machine tool
Control the feed axis, spindle, and tool magazine to achieve precision machining and automatic tool changing functions.
Automatic production line
Drive assembly, conveying, and sorting equipment to achieve efficient synchronous operation.
industrial robot
Control robot joints or end effectors to achieve precise multi axis motion.
Packaging and Printing Machinery
Drive feeding, cutting, packaging and other equipment to achieve high-speed and high-precision production.
textile machinery
Control winding, tension, and feeding devices to improve production efficiency and process stability.
Experimental and testing platform
Used for servo test benches and multi axis experimental devices to achieve precise motion control and data acquisition.
Product details picture:
503-19515-20
