GIDINGS&LEWIS 503-25909-00 Input Analog Module

Product manual:

GIDINGS&LEWIS 503-25909-00 Input Analog Module
Product Overview

GIDINGS&LEWIS 503-25909-00 Input Analog Module is an industrial grade signal acquisition device,
Mainly used in CNC machine tools and automation control systems to convert external analog signals (such as voltage and current) into digital signals that can be processed by the controller.
This module has high precision, high stability, and anti-interference ability, suitable for real-time monitoring and control in complex industrial environments.

Technical parameters (typical characteristics, specific subject to actual model)

Input type: Analog voltage or current signal

Number of channels: Multi channel input, supporting simultaneous acquisition of multiple signals

Conversion accuracy: High resolution A/D conversion ensures accurate measurement

Response speed: Fast sampling to meet real-time control requirements

Electrical isolation: isolate the input channel from the controller to enhance anti-interference capability

Interface method: Standard industrial interface, compatible with G&L controllers and PLC systems

Installation method: Modular design for easy rack installation and expansion

Product application areas

CNC machine tool

Used to collect analog signals of spindle, feed axis, and cutting tools.

Provide precise feedback on speed, current, or temperature to ensure machining accuracy.

Automatic production line

Collect analog signals from sensors, flow meters, pressure sensors, and other devices.

Realize real-time monitoring and feedback control of production processes.

process control system

Parameter collection for continuous production processes such as chemical engineering, metallurgy, and papermaking.

Realize closed-loop control of equipment such as valves, motors, pumps, etc.

robot system

Obtain force sensors, position sensors, or other analog inputs.

Support high-precision, multi axis synchronous motion control.

Testing and experimental platform

Used for analog signal acquisition in experimental equipment or detection devices.

Provide high-speed and high-precision measurement capabilities to meet the needs of scientific research and quality inspection.

Product details picture:

503-25909-00
