GIDINGS&LEWIS 503-26842-00 isolator module
Brand:GIDDINGS & LEWIS
Model:503-26842-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
GIDINGS&LEWIS 503-26842-00 isolator module
Product manual:
GIDDINGS&LEWIS 503-26842-00 isolator module
1、 Product Overview
GIDDINGS&LEWIS 503-26842-00 is a signal isolation module for industrial control systems, mainly used to isolate and protect input/output signals in control systems.
Through electrical isolation, this module can prevent high voltage, interference, or fault signals from being transmitted to the CPU, I/O modules, and servo drives, thereby improving the safety and reliability of the system.
This module is widely used in CNC machine tools, automated production lines, robot systems, and other industrial control environments.
2、 Technical parameters (typical indicators, actual subject to physical object)
Module type: Signal isolation module
Isolation voltage: ≥ 1500 V AC (between input and output)
Signal type: digital and/or analog signal
Number of channels: Multi channel input/output isolation (depending on specific configuration)
Response time: ≤ 1 ms (typical value, suitable for real-time control)
Interface method: Modular slot design, compatible with GIDDINGS&LEWIS system bus
Working voltage: DC 5V/24V provided by the rack
Working environment: industrial grade temperature, anti vibration, anti electromagnetic interference
Status indication: LED indicates the working and signal status of the module
3、 Application scenarios
CNC machine tool
Isolate the spindle, feed axis, and limit switch signals to protect the CPU and I/O modules from overvoltage or interference.
Automatic production line
Isolate sensor, button, and actuator signals to improve the safety of the production line system.
robot system
Isolate signals from multi joint encoders, limit switches, and servo drivers to prevent the spread of faults.
Printing and packaging equipment
Isolate tension sensors and position detection signals to ensure precise control and equipment safety.
Process Control and Experimental Platform
In chemical, pharmaceutical, and testing experimental equipment, isolate key control signals to ensure system stability.
Product details picture:
503-26842-00
