GIDINGS&LEWIS 810-22360-01 Control Panel

Product manual:

Gidding&Lewis 810-22360-01 Control Panel: Application Scenarios
Overview

This control panel (also known as the operation panel) is typically integrated into Giddings&Lewis' CNC numerical control system or PLC control system,
Used for interaction between machine operators and control systems.

Typical application scenarios

CNC machine interface interaction

Provide buttons, knobs, toggle switches, etc. for operators to start/stop the machine, select programs, set parameters, manually fine tune, and perform other operations.

Equipment status and alarm display

Real time display of machine status, alarm information, and system errors helps to quickly diagnose and respond.

Operation mode selection

Switch between multiple operating modes such as automatic/manual/semi-automatic to adapt to different processing flows.

Production process control

Can be used to select processing cycles, set process sequences, start/pause overall processes, and achieve production rhythm control.

Emergency control function

Integrate or connect the "emergency stop" button to quickly cut off power or interrupt machine operation, ensuring safety.

Simple parameter setting or debugging

Used for on-site adjustment of control parameters, facilitating maintenance, trial operation, and debugging operations.

Multi system universal interface module

In multi machine systems with unified interface requirements, it can serve as a standard operating end to enhance consistency and user familiarity.

System maintenance and upgrade support

As a modular front-end, system upgrades or higher functional support can be achieved by replacing the operation panel, reducing downtime.

Product details picture:

810-22360-01
