GIDINGS&LEWIS ASIU-A2 Analysis Unit Module

Product manual:

Product Overview

The GIDINGS&LEWIS ASIU-A2 analysis unit module is a high-performance signal processing unit designed for input signal acquisition and analysis in CNC machine tools and industrial automation systems. This module is capable of real-time monitoring and processing data from sensors
The analog or digital signals of encoders and other input devices provide precise judgment basis for the controller, ensuring the accuracy of action execution and the stability of system operation.
The ASIU-A2 module has the characteristics of fast response, high reliability, and easy scalability.

Technical parameters (typical)

Input type: Supports multiple analog and digital inputs

Sampling rate: high-speed signal acquisition, millisecond level response

Signal processing capability: filtering, amplification, conversion, and state judgment functions

Communication interface: Industrial bus or dedicated control interface, compatible with G&L controllers

Power supply: Industrial standard voltage

Protection function: overcurrent, overvoltage, short circuit, and signal abnormality protection

Installation method: Modular design, convenient for cabinet or rack installation and expansion

Environmental adaptability: anti vibration, anti impact, suitable for industrial environments

Application scenarios

Numerical Control Machine Tool System

Real time analysis of tool position, feed axis, and spindle sensor signals, supporting high-precision machining control.

Servo drive and closed-loop control

Provide sensor and encoder signal analysis to achieve precise control of servo motors.

Automatic production line

Analyze multi station sensor inputs, assist control device synchronization, and process judgment.

Industrial Robot System

Real time analysis of sensor signals from joints or end tools to achieve high-precision motion adjustment.

Packaging and Printing Machinery

Analyze sensor signals during feeding, cutting, and packaging processes to ensure synchronized actions and stable processes.

Experimental and testing platform

Analyze multi-channel experimental data to provide a basis for action control and data recording.

Product details picture:

ASIU-A2
