GIDINGS&LEWIS DSA-175-230S servo drive

Product manual:

GIDINGS&LEWIS DSA-175-230S servo drive
1、 Product Overview

DSA-175-230S is a high-power AC servo drive in the Giddings&Lewis series, used for precise control of high-performance servo motors. It can provide closed-loop speed, position, and torque control, widely used in CNC machine tools, automated production lines, and robot systems to achieve high-speed and high-precision motion control.

2、 Technical features

Rated input: 230VAC three-phase power supply, in compliance with industrial voltage standards.

Output power: Suitable for medium to high power servo motors, with both continuous and instantaneous overload capabilities.

Control mode: Supports closed-loop control modes of position loop, speed loop, and torque loop to meet different application requirements.

Feedback interface: compatible with high-resolution encoders or Hall sensors, achieving precise closed-loop control.

Protection function: Built in overcurrent, overvoltage, undervoltage, short circuit, and over temperature protection to improve system safety.

Modular design: easy to integrate with controllers, I/O modules, and servo motors, facilitating system expansion.

3、 Application Fields

CNC machine tool

Drive the spindle and feed axis of the machine tool to achieve high-speed and high-precision machining.

Control the actions of fixtures, hydraulic systems, and auxiliary equipment.

Automatic production line

Control the execution mechanisms of handling, assembly, and inspection to achieve process automation.

Support quick start stop and frequent reversing actions.

robot system

Drive robot joints to achieve closed-loop position and velocity control.

Suitable for precision tasks such as handling, welding, spraying, sorting, etc.

Packaging and Printing Machinery

Control feeding, slitting, tension, and synchronous actions to achieve high-quality production.

Logistics and Material Handling

Control conveyors, stackers, and automatic storage equipment to achieve precise positioning and synchronized handling.

Product details picture:

DSA-175-230S
