GIDINGS&LEWIS M.1301.2073 Graphic Touch Screen

Product manual:

1、 Product Overview

GIDINGS&LEWIS M.1301.2073 Graphic Touch Screen is a human-machine interface (HMI) device designed specifically for industrial automation and CNC machine tools.
It provides operation, monitoring, and control functions through an intuitive graphical interface, allowing operators to view device status in real-time
Adjust parameters and manage production processes. The touch screen combines high-resolution display and touch operation to enhance system visualization and operational convenience.

2、 Technical parameters (typical characteristics)

Model: M.1301.2073

Type: Graphic Touch Screen (HMI)

Display feature: High resolution color LCD display

Touch mode: resistive or capacitive touch, supports multi touch (depending on specific configuration)

Interface: Supports industrial communication interfaces such as Ethernet, serial port, USB, etc

Operating System/Firmware: Industrial grade operating system, supporting custom interfaces and controls

Installation method: panel embedded or bracket installation, convenient for device integration

Industrial adaptability: resistant to high temperature, high humidity, vibration and electromagnetic interference

3、 Application scenarios

Numerical Control Machine Tool (CNC)

Real time display of machine status, machining program, and alarm information

Provide parameter adjustment, program start/stop, and operation control interface

Automatic production line

Monitoring robotic arms, conveying equipment, and sorting systems

Operable multi device coordinated control and production process management

Packaging and Printing Machinery

Display production pace, equipment status, and product quality information

Support operators to adjust production parameters in real-time

Experimental and testing equipment

Provide data monitoring, experimental status display, and parameter setting interface

Support visualization of experimental processes and recording of results

Industrial Automation Monitoring System

As a system human-computer interaction interface, it realizes device management, alarm monitoring, and data viewing

Seamless integration with controllers, PLCs, or CPU modules

Product details picture:

M.1301.2073
