GIDINGS&LEWIS M.1301.9806 Thermocouple Module
Product manual:
Product Overview
Giddings&Lewis M.1301.9806 is a thermocouple input module in the PiC series control system, used to collect temperature signals in industrial processes.
It converts the weak voltage signal output by the thermocouple sensor into a standard signal that can be processed by the controller,
Realizing temperature monitoring and control is an important component of high-precision machining equipment and industrial automation systems.
Product Features
High precision temperature acquisition
Support multiple types of thermocouples (such as K, J, T type) to meet different industrial temperature measurement needs.
Built in cold end compensation function ensures temperature measurement accuracy.
Multi channel input
It can simultaneously process multiple thermocouple signals to achieve multi-point temperature monitoring.
Support modular expansion to meet complex system requirements.
Signal isolation and protection
Electrical isolation between input and controller enhances anti-interference capability.
Anti overcurrent and anti short circuit design ensures the safety of modules and control systems.
Industrial environment adaptability
Anti vibration and anti impact design, suitable for machine tools and automated production environments.
EMC has strong anti-interference ability, ensuring long-term stable operation.
Status indication and convenient maintenance
LED indicates the operating status of the module for easy on-site monitoring.
Modular design, convenient for installation, debugging, and replacement.
Application field
Numerical Control Machine Tool: Monitor the temperature of the machining area or spindle to prevent overheating from affecting machining accuracy.
Industrial automation production line: Collect the temperature of key equipment to achieve automatic temperature control and protection.
Process control system: Real time monitoring and control of furnace temperature, liquid or gas temperature.
Experimental and testing equipment: used for temperature data collection, analysis, and process control experiments.
Equipment safety and maintenance: achieve overheating alarm and fault protection through temperature monitoring
Product details picture:

M.1301.9806
