GIDINGS&LEWIS M.1302.7764 Input Module
Brand:GIDDINGS & LEWIS
Model:M.1302.7764
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
GIDINGS&LEWIS M.1302.7764 Input Module
Product manual:
GIDINGS&LEWIS M.1302.7764 Input Module
Product Overview
Giddings&Lewis M.1302.7764 is an industrial grade digital/analog input module,
Used for receiving signals from sensors, switches, and other input devices in CNC systems and automation control systems.
It converts external physical signals into digital or analog data that can be processed by the central control board, thereby achieving precise control of mechanical actions, production processes, and monitoring systems.
Technical parameters (typical characteristics)
Module type: Digital/Analog Input Module
Number of input channels: Depending on the system configuration, it usually supports 8 to 16 channels
Signal type:
Digital input (switch quantity, pulse signal)
Analog inputs (voltage, current signals)
Sampling accuracy: 16 bits (analog signal)
Response time: microsecond level, suitable for real-time control
Power requirement:+5V DC logic power supply (typical value depends on the system)
Status indication: LED indicates input status and diagnostic information
Environmental conditions:
Working temperature: 0 ° C~55 ° C
Humidity: 5%~95%, no condensation
Protection functions: short circuit protection, overvoltage protection, signal isolation design
Application scenarios
Numerical Control Machine Tool (CNC)
Receive travel switches, limit sensors, and tool detection signals for machining process control.
Industrial automation production line
Used to read signals from sensors, photoelectric switches, pressure switches, etc., to achieve workstation logic control.
robot system
Receive signals from end effector status, position sensors, and limit switches to achieve precise action control.
Packaging and Printing Equipment
Collect input signals from material sensors, tension sensors, speed sensors, etc. to ensure synchronized actions.
Testing and experimental platform
Collect analog signals such as temperature, pressure, and current for equipment debugging and experimental data collection.
Product details picture:
M.1302.7764
