GIDINGS&LEWIS M.1302.7848 digital spool module
Brand:GIDDINGS & LEWIS
Model:M.1302.7848
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
GIDINGS&LEWIS M.1302.7848 digital spool module
Product manual:
GIDDINGS&LEWIS M.1302.7848 digital spool module
1、 Product Overview
GIDDINGS&LEWIS M.1302.7848 is a Digital Spindle Module for industrial control systems,
Used for digital control of the speed, direction, and position of machine tool spindles or other rotating axes.
This module can be combined with servo drivers, CPU modules, and encoders to achieve high-precision rotation control, closed-loop speed regulation, and multi axis coordinated control.
Its modular design facilitates installation and maintenance in CNC machine tools, automated production lines, and high-precision machining equipment.
2、 Technical parameters (typical indicators, actual subject to physical object)
Module type: Digital spool module
Control object: spindle or rotation axis
Input signal: feedback from digital encoder, CPU instruction signal
Output signal: servo drive control signal
Speed control range: continuously adjustable from high speed to low speed (depending on system configuration)
Accuracy: Micron level positioning and speed control, supporting closed-loop control
Interface method: Modular slot design, compatible with GIDDINGS&LEWIS series bus systems
Working voltage: DC 5V/24V provided by the rack
Working environment: Industrial grade temperature range, anti vibration and anti electromagnetic interference
Status indication: LED indicates module operation, fault, and communication status
3、 Application scenarios
CNC machine tool
Accurately control the spindle speed and position to achieve complex cutting, drilling, and milling operations.
Support multi axis synchronous control and high-speed interpolation machining.
Automatic production line
Control the rotating conveyor shaft, material distribution shaft, or winding shaft to achieve production rhythm and process coordination.
robot system
Control rotary joints or rotary platforms to achieve high-precision positioning and trajectory control.
Printing and packaging equipment
Control the winding, tension shaft, and rotating feeding device to achieve high-precision printing and packaging.
Experimental and Testing Platform
Control the rotating platform or testing axis to achieve high-precision angle and speed control during experiments or testing processes.
Product details picture:
M.1302.7848
