GIDINGS&LEWIS SMP400 Controller Module

Product manual:

Product Overview

The GIDINGS&LEWIS SMP400 controller module is a high-performance core processing unit for CNC systems. It is used to coordinate various action instructions of machine tools or automation equipment, process signals from input modules, sensors, and operation terminals, and generate precise control instructions to drive the execution mechanism. The SMP400 module is renowned for its high-speed processing capability, stability, and scalability, and is the core control component of multi axis CNC machine tools and industrial automation systems.

Technical parameters (typical)

Processing capability: High speed digital signal processor, supporting multi axis motion control

Communication interface: Supports industrial standard bus and G&L dedicated control interface

Input/output support: can manage multi-channel digital and analog signals

Program storage: Built in high-speed memory, capable of storing complex machining programs and logical instructions

Scalability: Supports collaborative work with external devices such as servo drives, execution control boards, input analysis modules, etc

Real time performance: millisecond level instruction processing capability, meeting the requirements of high-speed and high-precision machining

Protection mechanism: Overload, short circuit, overvoltage, and signal abnormality protection

Installation method: Modular design, convenient for cabinet or rack integration

Application scenarios

multi-axis nc machine tool

Control the spindle, feed axis, and tool magazine to achieve complex machining actions and automatic tool changing functions.

Automatic production line

Coordinate assembly, conveying, and sorting stations to achieve action synchronization and process control.

Industrial Robot System

Manage multi joint robotic arms and end tools to achieve precise trajectory control and collaborative operation.

Packaging and Printing Machinery

Control feeding, cutting, and packaging actions to ensure high-speed and high-precision production.

Textile and Special Craft Equipment

Drive winding, tension, and feeding systems to achieve high-precision production and process control.

Experimental and testing platform

Support multi-channel servo test benches or experimental equipment to achieve precise execution of complex action sequences.

Product details picture:

SMP400
