GJR2365700R1010 88VA02B-E Control Board Assembly
Brand:ABB
Model:GJR2365700R1010 88VA02B-E
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
GJR2365700R1010 88VA02B-E Control Board Assembly
Product manual:
ABB GJR2365700R1010， The model is 88VA02B-E, which is an industrial grade control board assembly,
Mainly used in ABB Symphony Harmony series distributed control systems (DCS),
The acquisition and isolation processing function of digital signal input is one of the important interface modules between the system and on-site equipment.
1、 Basic Product Information
Product Code: GJR2365700R1010
Model: 88VA02B-E
Product Type: Digital Input Control Board Assembly (DI Control Assembly)
Number of channels: 32 digital inputs
Working voltage: 24V DC signal input
Signal reception: suitable for dry contacts or active 24V input devices
Public signal return: share a set of grounding circuits
Electrical isolation: Each channel is isolated from the logic circuit to enhance anti-interference performance
Communication compatibility: compatible with ABB MasterBus 300 communication architecture
Module form: Board assembly, including motherboard and interface connection unit
2、 Functional Features
Transmit the on-site contact switch signal to the control system
Each channel is equipped with status detection and protection circuits
Can be used in conjunction with SC510 or SC520 baseboard
Provide LED status indication for easy on-site maintenance
Suitable for long-term operation in high temperature and electromagnetic interference environments
3、 Typical application areas
Power system: used to collect status signals of circuit breakers, isolating switches, grounding knives, etc
Petrochemical and chemical industry: detecting limit switches, safety signals, etc. in the production process
Rail transit: used to collect the status of turnouts and signals
Steel and Metallurgy: Monitoring Limits and Safety Signals in Processes such as Continuous Casting and Rolling Steel
Water treatment and environmental protection industry: real-time collection of signals such as pump start stop and water level alarm
Product details picture:
