HG4G-CJT22TF-B color LCD display screen

Product manual:

HG4G-CJT22TF-B is an industrial color LCD display screen designed specifically for human-machine interfaces (HMI) in automation systems and industrial equipment.

Module Overview

The HG4G-CJT22TF-B color LCD display screen can intuitively display the control system status, operating parameters, and real-time data, making it convenient for on-site operators to monitor and control equipment. It is typically used in conjunction with controllers, PLCs, or I/O modules to provide a touch or button operated interface.

Main functions

real-time display

Display device status, sensor data, and control parameters.

Support multi window and multi page information switching.

human-computer interaction

Touch screen operation or button control, providing an intuitive operating interface.

It can achieve parameter input, command issuance, and alarm confirmation.

Alarm Alert

Notify equipment abnormalities or process alarms through visual or auditory cues.

data visualization

Support chart, curve, and graphical data display for easy analysis of equipment operation.

communication interface

Connect with PLC, controller or upper computer system through standard industrial interfaces (such as RS-232, RS-485, Ethernet, etc.).

Technical Features

High resolution color display with clear display effect.

Industrial grade design, high temperature resistance, vibration resistance, and electromagnetic interference resistance.

Modular installation, easy to maintain and replace.

Supports multiple display modes and custom interface layouts.

Typical Applications

Operation and monitoring interface of industrial automation production line.

Real time display of process parameters and equipment status in the process control system.

Operation monitoring and alarm display of energy and power systems.

Visual operation interface for experimental and research platform equipment.

HG4G-CJT22TF-B Product details picture:

HG4G-CJT22TF-B product video
