HONEYWELL 51451397-501 Analysis Output Module

Brand:HONEYWELL
Model:51451397-501
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

HONEYWELL 51451397-501 Analysis Output Module

Product manual:

HONEYWELL 51451397-501 analysis output module is a key component in Honeywell process control systems
Belonging to the I/O module in the architecture of the Expert PKS/TDC 3000/C300/TPS system.
This module is mainly used to output and analyze data from the control system, such as gas and liquid composition analysis results
Commonly used for integration of analytical instruments and data transmission in process control.

1、 Basic Product Information
Brand: HONEYWELL

Model: 51451397-501

Name: Analytical Output Module

Applicable systems: TDC 3000, Expert PKS, TPS, C300 or certain legacy control systems

2、 Functional Features
Analysis data output: will come from analytical instruments

Analog output capability: Output standard current/voltage signals, such as 4-20 mA,
Used to drive actuators or transmit data to the upper computer;

Supports multiple output channels: typically with 2-8 analog outputs that can be independently configured;

Redundancy support: Can be configured as hot backup or dual module redundancy to improve reliability;

Status and fault diagnosis function: supports module self status monitoring and output channel fault alarms.

3、 Typical technical parameters (estimated values, for reference only)
Number of analog output channels: 4 or 8 (to be confirmed)

Output type: 4-20 mA or 0-10 V

Output accuracy: ± 0.1% FS (depending on the system)
