HONEYWELL MC-PDOX02 51304487-150 Digital Output Module

Product manual:

HONEYWELL MC-PDOX02 51304487-150 is a digital output module,
The Process Manager (PM) control system platform, which belongs to the Honeywell Expert PKS or TDC3000 system architecture,
Used to convert the logic control signal of the controller into a digital signal output, driving external execution devices such as solenoid valves, relays, alarms, etc.

1、 Overview of Basic Information
Project Content
Product Name: Digital Output Module
Model MC-PDOX02
Part number 51304487-150
Manufacturer Honeywell
System platform TDC3000, Expert PKS, PlantScape
Module type: Multi channel digital output module

2、 Function Description
Main functions:
Output the control commands (such as logic on/off) issued by the controller to the on-site equipment to achieve switch driven control.

Number of channels:
Usually supports 16 point digital output (the specific number of channels depends on the sub model).

Output format:
Open collector type output, solid-state relay output, or transistor output (to be confirmed in the technical manual).

Load driving capability:
It can directly drive low-power loads (such as LED indicator lights, electromagnetic relays, etc.) or relay driven contactors.

Status indication:
The panel is equipped with LED indicator lights, and the output status of each channel is displayed in real-time.

3、 Typical application scenarios
Application Domain Control Object or Function Description
Chemical/petroleum/natural gas solenoid valve on/off, pump on/off, signal light output
Power plant/power system control circuit breakers, auxiliary equipment switches, alarm drives
Water treatment/environmental protection water pump, dosing device, valve control
Production line automation lighthouse alarm, motor control start stop, actuator status switching
Building control system exhaust/smoke exhaust system, alarm system output, access control

Product details picture:
