IC9445A200B limit switch

Brand:GE
Model: IC9445A200B
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

IC9445A200B limit switch

Product manual:

IC9445A200B is an industrial grade limit switch launched by GE Fanuc (an automation product line under General Electric), commonly used for position detection and action control.

2、 Product Features
Mechanical limit action detection

Modular design: easy to install and replace

Sealed structure: suitable for harsh industrial environments (such as dust, oil mist, etc.)

Dual loop control: can be used for redundant feedback or multi-stage control

High repeatability accuracy: suitable for high-frequency motion systems

High protection level: suitable for humid and vibrating environments

3、 Technical specifications (reference values, model specific parameters please refer to the nameplate)
Project Description
Model IC9445A200B
Type: Mechanical limit switch
Action type: Rotary actuator arm or roller type (depending on sub model)
Contact configuration 1NO+1NC or 2NC (common configuration)
Rated voltage 250 VAC/125 VDC (maximum)
Rated current 10A (resistive load)
Contact life exceeds 1 million mechanical operations
The mechanical lifespan is usually greater than 10 million actions
Protection level IP65 (typical model)
Working temperature range -25 ° C~+70 ° C
Installation method: bolt fixed, with standard installation holes
Shell material: metal or high-strength engineering plastic (depending on the model)

4、 Typical application scenarios
Limit detection of CNC machine tools

Automated assembly line endpoint feedback

Limit protection for lifting equipment

Travel control of conveying system

End position confirmation of industrial robots

High precision assembly system positioning signal input

5、 Usage suggestions
Wiring Attention: Strictly distinguish between normally open (NO) and normally closed (NC) contacts to avoid accidental triggering

Installation position: Ensure stable and reliable contact between the action arm or roller and the moving mechanism

Regular inspection: It is recommended to regularly check the switch status and contact wear to ensure reliable operation

Environmental adaptation: Avoid use in highly corrosive environments. If there is an explosion-proof requirement, please confirm whether it has explosion-proof certification
