IS200FGPAG1A amplifier module

Product manual:

IS200FGPAG1A is an amplifier module designed by General Electric for the LS2100 series static starting system
Mainly used to drive the gate signal of the thyristor and monitor its status to ensure the stable operation of the power system during the start-up phase

Core functions
One control gate trigger
The module receives the gate signal from the main control board and amplifies it for power
Used to drive high-voltage thyristor devices

Two state feedback monitoring
Real time feedback of SCR conduction status and operating voltage value by the module
Assist the control system in determining switch status and fault conditions

Three power supply voltage conversion
Transform the input power supply into low-voltage DC power suitable for internal circuits for control and signal processing

Four system collaborative control
Collaborate with multiple sub boards in the LS2100 control platform to achieve complete startup control logic

Technical Parameter
The compatible systems are LS2100 and LS2100e
The working voltage level includes 2300V three-phase or 4160V and 6600V systems
Supports synchronous operation of up to six bridge arm structures
Typically installed inside the bridge cabinet and connected to the main control board through busbars and signal lines
The standard operating temperature range is from minus 20 degrees Celsius to 70 degrees Celsius
The weight of the module is approximately 0.9 kilograms
The module size is 61 centimeters by 51 centimeters by 51 centimeters

Application scenarios
Suitable for heavy-duty gas turbine static starting system
High voltage and high-power motor drive system
Variable frequency starting control system for industrial power plants
In situations where logic control and status feedback are carried out in conjunction with the SCR drive module

Product details picture:
