JGSM-06 Position Controller

Product manual:

The JGSM-06 position controller is a control unit used in industrial automation systems to perform position control and adjustment. It is typically paired with sensors, servo mechanisms, or actuators to achieve precise position feedback and control.

main purpose

Accurately control and adjust the position of mechanical equipment.

Receive feedback signals from position sensors such as encoders and displacement sensors.

Generate control outputs based on the set target position to achieve the positioning of the actuator.

Linked with PLC, DCS and other controllers, used for positioning tasks in process automation.

core functionality

Location acquisition: Read real-time location signals from sensors.

Error calculation: Compare the actual position with the target position and calculate the deviation.

Control output: Based on the deviation output control signal, drive the actuator to correct the position.

Closed loop control: Implement feedback regulation to maintain stable positioning accuracy.

Setting adjustment: Target position, response speed, control parameters, etc. can be set.

Main Features

High precision positioning: suitable for automation applications that require precise position control.

Fast response: Short control response time, suitable for dynamic position adjustment.

Strong stability: with anti-interference ability, suitable for industrial site environment.

Typical application scenarios

Mechanical arm or robot joint position control.

Automatic feeding, positioning, and positioning stop control.

Accurate adjustment of the position of equipment such as rollers and conveyor belts.

CNC、 Position feedback control of machining centers such as grinders and drilling machines.

Accurate opening control of air doors, valves, access control and other equipment.

Component positioning control for automated assembly lines.

Position adjustment of machine tool worktable or slide table.

Position adjustment unit in servo motor/stepper motor closed-loop control system.

Collaborate with PLC system to achieve multi axis position linkage control.

Comparison and adjustment of target position setting and real-time feedback in motion control systems.

JGSM-06 Product details picture:

JGSM-06 product video
