KEBA E-3-ACU-INC D1671B Printed Circuit Board

Product manual:

Product Name:
KEBA E-3-ACU-INC D1671B Printed Circuit Board

Product Overview:
This circuit board is the incremental encoder interface board (ACU-INC) in the KEBA automation control system,
Used to receive signals from incremental encoders and convert them into feedback data recognizable by the controller,
Used for high-precision motion control and position feedback.

Technical parameters:
Model: E-3-ACU-INC D1671B

Function: Incremental encoder signal input and processing

Input type: A/B/Z phase encoder signal, TTL or differential signal

Channel count: Supports single or multi-channel encoder input

Interface method: Standard industrial signal interface (slot type)

Power supply: 24V DC or internal power supply of the control system

Installation method: Modular plug-in structure, suitable for KEBA control rack

Application areas:
Precision motion control system

Axis position monitoring of injection molding machines and extruders

Servo feedback system for automated production line

Robot joint position detection

Position feedback interface module for CNC equipment

Product features:
High speed signal sampling ensures precise response of the control system

Seamless integration with KEBA control system

Industrial grade anti-interference design ensures stable signal transmission

Modular structure, convenient for replacement and maintenance

Supports multiple encoder signal types with strong adaptability

Product details picture:

E-3-ACU-INC D1671B
