KEBA E-FLOPPY circuit board

Product manual:

The KEBA E-FLOPPY circuit board is a Floppy Interface Board used in KEBA automation control systems,
Mainly used to provide connection function with floppy disk drives.
This module was used in early automation systems or industrial control equipment for storing and loading program, parameter, and recipe data,
Especially suitable for older control systems that do not have modern USB or Ethernet interfaces.

Technical Parameter
Product Name: E-FLOPPY

Function type: Floppy drive control and interface circuit board

Compatible drive type: 3.5-inch floppy disk drive (FDD, Floppy Disk Drive)

Interface type: 34 pin floppy drive standard interface+control logic interface

Applicable system: KEBA early control system or equipment based on E-series main control platform

Power requirement: Typically 5V DC (from the main control system)

Installation method: Modular plug-in or panel embedded installation

Transmission rate: Complies with FDD standards, approximately 250kbps (depending on the controller)

Application scenarios
Old style injection molding machine or console

Used to load process parameters, factory settings, or program data from floppy disks

Cooperate with KEBA main control card to update software or backup data for old devices

Early industrial automation equipment

File data transmission for printing, packaging, textile and other machinery

As the primary data carrier interface in an environment without network support

System maintenance and fault diagnosis

Engineers read system logs or download system configurations through floppy disks

Convenient for remote or offline maintenance and recovery operations

OEM equipment integration

E-FLOPPY is used as a persistent storage interface in some customized devices

Build an independent control system in conjunction with KEBA panel, keyboard, and controller

Product details picture:

E-FLOPPY
