KEBA E-HSI-RS485 circuit board

Product manual:

KEBA E-HSI-RS485 is an RS-485 communication interface circuit board designed specifically for KEBA automation systems,
Used to achieve reliable serial data communication in industrial environments.
It supports multi-point communication based on the RS-485 standard and is often used for data exchange between devices,
Such as sensors, actuators, frequency converters, PLCs, or external control devices.
This module is suitable for HSI (High Speed Interface) in the KEBA KeControl series
Expansion function board is one of the key communication components in the system that connects peripherals.

Technical Parameter
Product model: E-HSI-RS485

Function type: RS-485 communication expansion circuit board

Communication protocol: Supports standard RS-485 half duplex communication

Communication speed: Supports up to 1 Mbps (depending on line length)

Interface form:

Terminal block or plug-in interface (depending on the system integration method)

May support configurable terminal resistors

Insulation protection: equipped with photoelectric isolation to enhance electrical safety

Installation method: Modular insertion into the main control system slot or connection to the backplane

Power supply requirements: 5V or 24V provided by the main system (depending on the internal power architecture)

Compatible platforms: KEBA KeControl/KePlast/KeMotion and other system platforms

Application scenarios
Expansion of communication interface for injection molding machine or extruder

Used to connect external temperature control modules, weighing systems, or distributed control nodes

Multi point communication capability supports linkage between complex devices

Communication between frequency converter or servo drive

Realize parameter reading and writing of third-party driving devices through RS-485

Support industrial communication protocols such as MODBUS RTU

Fieldbus communication

Connect sensors, instruments, operation panels, and other devices using RS-485 interfaces

Building a multi master and multi slave control structure

Industrial networking and long-distance communication

Stable remote device serial communication in factory environment (up to 1200 meters)

Improve the scalability of automation systems

Product details picture:

E-HSI-RS485
