KEBA T50-ADP teaching pendant

Brand:KEBA
Model:T50-ADP
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

KEBA T50-ADP teaching pendant

Product manual:

Product Overview:
The KEBA T50-ADP teaching pendant is a mid to high end human-computer interaction device launched by KEBA,
As a member of the T50 series, T50-ADP has standard functions such as touch screen, function buttons, and safety control components,
Supports multiple language operation interfaces and is suitable for various types of automation devices.

Technical parameters:
Display screen: 7-inch TFT color LCD touch screen

Resolution: 800 × 480 (WVGA)

Touch mode: resistive touch screen, supports glove operation

Control buttons:

Multiple programmable function keys

Physical buttons for direction control, confirmation, start/stop, etc

Security function:

Red emergency stop button (compliant with EN ISO 13850)

Three stage enable switch (held with left or right hand)

Communication interface:

USB interface (program import and export)

Ethernet or dedicated communication port (connected to controller)

Power supply method: Powered by the main system, typically 24V DC

Structural design:

Industrial grade impact resistant shell

Dustproof and oil proof design, suitable for harsh environments

Weight: Approximately 1.2-1.5 kg (suitable for long-term handheld operation)

Working environment temperature: 0 ° C to+50 ° C

Application areas:
1. Industrial robot path teaching
Used for teaching path points, trajectory planning, speed debugging, etc. of six axis or multi axis industrial robots.

2. Injection molding and rubber forming machines
Real time monitoring of process parameters such as mold locking, injection, and pressure maintenance for quick modification and operation.

3. Debugging of automated production line
Control subsystem equipment such as conveying, assembly, loading and unloading to facilitate troubleshooting and status checks.

4. Packaging and labeling equipment human-machine operation
Manually assist in the operation and parameter setting of functions such as heat sealing, labeling, and film feeding.

5. System maintenance and fault diagnosis
Support operation and maintenance operations such as device log viewing, alarm management, and device testing instruction sending.
