KLA Tencor 710-302407-00 Interface Module
Brand:KLA-Tencor
Model:710-302407-00
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
KLA Tencor 710-302407-00 Interface Module
Product manual:
KLA Tencor 710-302407-00 Interface Module
Product Introduction
The KLA Tencor 710-302407-00 interface module is a critical control component used in semiconductor manufacturing equipment,
The main task is to achieve data communication and signal coordination between various subsystems.
This module is widely used in optical inspection, defect recognition, wafer positioning, and other precision equipment,
major function
Signal Conversion and Routing
Convert command signals from the upper control system into ones suitable for lower level devices
Control signals for sensors, actuators, etc.
Reverse collect device feedback information and transmit it back to the main control system for logical judgment.
Data communication interface management
Manage multiple communication protocols (such as RS-232/485, I2C, SPI, Ethernet, etc.)
Adaptation and switching.
Support multi-channel signal synchronization and multitasking communication.
Modular design
Support hot swappable and backplane interface connection, easy to maintain, replace or expand the system.
Technical specifications (reference)
Input/Output Types: Digital I/O, Analog I/O, Communication I/O Hybrid
Number of signal channels: 8-32 channels (depending on configuration)
Supported protocols: RS-232, RS-422, CAN, Ethernet, I/O Bus, etc
Power input:+5V or+12V DC (depending on the model)
Working temperature range: 0 ° C~50 ° C
Installation method: rack mounted or backplane connected
Communication speed: Supports up to 115.2kbps (serial) or higher speed (Ethernet)
Typical application areas
Wafer inspection equipment
Used to connect the main control unit with motion control components, imaging units, light source control circuits, etc.
Image Processing System
Realize high-speed communication between the image acquisition module and the data processing module.
Motion Control Subsystem
Drive and provide precise signal feedback for modules such as stepper motors and servo controllers.
Detection and feedback closed-loop system
Real time control logic for executing sensor data feedback and instruction output.
Remote management of equipment
Support remote configuration, device status reporting, and diagnostic information feedback.
Product details picture:
