KLA Tencor 710-611538-000 power module

Brand:KLA-Tencor
Model:710-611538-000
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

KLA Tencor 710-611538-000 power module

Product manual:

The KLA Tencor 710-611538-000 power module is a high reliability power component designed specifically for KLA Tencor detection and measurement equipment,
Mainly used to provide stable DC power supply for modules such as control boards, interface boards, image processing units, and motion platforms inside the equipment.

1、 Product Overview
Product model: 710-611538-000

Type: Power Supply Module

Manufacturer: KLA Tencor

Application scope: Power supply and voltage regulation, compatible with internal modules of 710 series control systems

2、 Main functions
Multi channel DC output power supply

Provide multiple voltage levels (such as+5V,+12V, -12V,+24V, etc.), suitable for various digital/analog circuits.

Support components such as drive control board, sensor interface, motor controller, camera module, etc.

High stability and voltage accuracy

Ensure stable voltage output under full load and load fluctuations, and guarantee the reliability of detection system data.

Improved protection mechanism

Equipped with protection functions such as overvoltage, overcurrent, short circuit, and high temperature, it enhances the safety of system operation.

Electromagnetic Compatibility Design (EMC)

Strong anti-interference ability helps to reduce signal noise and improve the stability of image and measurement systems.

3、 Product application areas
1. Wafer Inspection System
Power supply for the motion platform controller, image acquisition card, and laser control system.

Stable power supply can avoid detecting image jitter and false triggering.

2. Optical Measurement System (Metrology Equipment)
Provide voltage stabilization support for interferometer modules, Z-axis control boards, feedback loops, etc.

3. Automated processing platform
Support the power supply requirements for wafer handling units, robotic arm control modules, and safety interlock circuits.

4. Image acquisition and processing system
Ensure the power continuity of the image acquisition card, signal amplifier, and synchronous triggering module.
