KLA Tencor 710-611867-000 Image Board

Product manual:

KLA Tencor 710-611867-000 Imaging Board
It is a key image acquisition and processing module in KLA Tencor's high-end semiconductor testing equipment
Responsible for receiving image signals from optical sensors or cameras, and performing preliminary processing and data transmission,
Provide high-quality image data support for subsequent defect detection and analysis.

1、 Basic Product Information
Model: 710-611867-000

Type: Imaging Board

Series: KLA Tencor 710 Series

Main functions: High performance image signal acquisition, primary image processing, and data interface management

2、 Main functions and features
Function Description
Image signal acquisition is connected to optical sensors such as CCD and CMOS to capture high-resolution image signals in real time
Image preprocessing includes noise filtering, gain adjustment, image enhancement, etc., to improve image quality
High speed data transmission transmits image data to the main processing unit through high-speed buses (such as PCIe, dedicated high-speed interfaces)
Synchronize control with scanning platforms, laser sources, and other equipment to ensure accurate image acquisition timing
Multi channel support supports multiple image signal inputs, enabling multi-sensor collaborative acquisition
Stable and reliable industrial grade design, suitable for high-frequency operation requirements in complex semiconductor manufacturing environments

3、 Application Fields
Surface defect detection of wafers
Collect high-resolution surface images for defect recognition, localization, and classification.

Automatic Optical Inspection (AOI) System
Realize fast and high-quality image acquisition, support high-speed online detection.

Optical measurement equipment
Provide imaging data foundation, assist in morphology analysis, thickness measurement and other functions.

Electron Beam (e-beam) Imaging System
In electron beam detection equipment, it is used to collect secondary electron images or other signals.
