KLA Tencor 710-650879-20 Driver Component

Brand:KLA-Tencor
Model:710-650879-20
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

KLA Tencor 710-650879-20 Driver Component

Product manual:

KLA Tencor 710-650879-20 Driver Component (Dual Stepper Driver PCB)
It is an important electronic module specifically designed for KLA Tencor wafer inspection equipment,

Detailed Function Description
Stepper motor drive control

This component can accurately control the rotation of multiple stepper motors,
Realize the positioning and movement of wafer inspection equipment robotic arms or transport systems.

By receiving pulses and directional signals from the main control unit,
Drive the motor to move according to the preset program, ensuring the accuracy and stability of the detection process.

Signal Conversion and Processing

Convert high-level control logic signals into motor drive signals,
Including the regulation of current and voltage, to ensure the smooth start, operation, and stop of the motor.

Having certain signal filtering and anti-interference capabilities,
Reduce the impact of external environment on signals and improve system reliability.

Multi axis drive support

Support synchronous or independent driving of multi axis stepper motors,
Meet the coordination requirements of complex actions and enhance the automation and flexibility of equipment.

Modular design

The driver components adopt a modular design, which facilitates quick replacement and upgrade by maintenance personnel,
Improve equipment maintenance efficiency.

Compact structure, suitable for installation in limited internal space of equipment.

Stability and durability

Design considering industrial environment, using components that are resistant to high temperature and vibration,
Ensure stability during long-term operation.

Equipped with overcurrent and overvoltage protection mechanisms to prevent circuit damage and ensure equipment safety.

Application scenarios
Wafer defect detection system
Such as the Surfscan series equipment, which drives the robotic arm to accurately position the wafer surface,
Ensure the comprehensiveness and high resolution of the detection.

Semiconductor manufacturing automation equipment
Control transmission devices, vehicles, and other actuators to achieve efficient and stable production processes.

Precision motion control system
Applied to various industrial automation equipment that requires high-precision positioning.
