KLA Tencor 740-607108-005 Electric PCB Card

Brand:KLA-Tencor
Model:740-607108-005
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

KLA Tencor 740-607108-005 Electric PCB Card

Product manual:

KLA Tencor 740-607108-005 Motorized PCB Card
It is an electric control board used in KLA Tencor high-end detection and measurement equipment,
Usually used to drive or control precision motion components, such as scanning platforms, lens movement, laser head positioning, Z-axis adjustment devices, etc.
It belongs to KLA's 740 series electronic platform and is an important component for achieving high-precision automated motion and feedback closed-loop control in equipment.

1、 Basic Information
Product model: 740-607108-005

Product Name: Electric PCB Card/Motorized PCB Board

Platform: KLA Tencor 740 Series

Application types: Drive control, motor management, motion feedback interface board

2、 Main functions
Function module description
Motor drive control controls stepper motors or servo motors to achieve precise actions such as linear movement, rotation, and Z-axis adjustment.
The feedback interface receives signals from encoders, limit switches, etc. to achieve closed-loop motion control.
Power allocation and regulation provide power to the actuator, with voltage and current regulation and current limiting protection.
Signal synchronization and triggering support synchronous execution of motion and sampling actions with the main control system.

3、 Typical application areas
1. Wafer scanning platform
Control the lateral (X-Y) or vertical (Z) movement of the platform to achieve full coverage of wafer inspection.

2. Auto focus/focusing mechanism
Used for precise adjustment of focusing components in optical systems, in conjunction with cameras to achieve clear imaging.

3. Camera or laser head moving device
Control the micro step drive of the lens group and laser head, supporting zoom, alignment, and height adjustment.

4. Wafer handling mechanism
Drive the vacuum adsorption arm, rotating device, transport platform, etc. to achieve automatic replacement and alignment.
